Product variants
Working load limit [kg]
for nominal chain thickness [mm]
Reference no.
Details
-
14006502275
B1H 10C-CPL-H-HIGH10-6MM-COAT
Reference no. 502275 Working load limit [kg] 1400 for nominal chain thickness [mm] 6 Hook opening width G [mm] 19 hook base height H [mm] 20 Hook thickness A [mm] 15 Distance suspension point E [mm] 73 Weight approx. [kg] 0.29 -
25008502277
B1H 10C-CPL-H-HIGH10-8MM-COAT
Reference no. 502277 Working load limit [kg] 2500 for nominal chain thickness [mm] 8 Hook opening width G [mm] 26 hook base height H [mm] 27 Hook thickness A [mm] 19 Distance suspension point E [mm] 98 Weight approx. [kg] 0.65 -
400010502278
B1H 10C-CPL-H-HIGH10-10MM-COAT
Reference no. 502278 Working load limit [kg] 4000 for nominal chain thickness [mm] 10 Hook opening width G [mm] 30 hook base height H [mm] 33 Hook thickness A [mm] 25 Distance suspension point E [mm] 113 Weight approx. [kg] 1.3 -
670013502279
B1H 10C-CPL-H-HIGH10-13MM-COAT
Reference no. 502279 Working load limit [kg] 6700 for nominal chain thickness [mm] 13 Hook opening width G [mm] 38 hook base height H [mm] 40 Hook thickness A [mm] 32.2 Distance suspension point E [mm] 133 Weight approx. [kg] 2.42 -
1000016502276
B1H 10C-CPL-H-HIGH10-16MM-COAT
Reference no. 502276 Working load limit [kg] 10000 for nominal chain thickness [mm] 16 Hook opening width G [mm] 45 hook base height H [mm] 48 Hook thickness A [mm] 38.5 Distance suspension point E [mm] 157 Weight approx. [kg] 3.45 -
1600020710037
B1H 10C-KPL-H-HIGH10-20MM-LACK
Reference no. 710037 Working load limit [kg] 16000 for nominal chain thickness [mm] 20 Hook opening width G [mm] 53 hook base height H [mm] 53 Hook thickness A [mm] 51 Distance suspension point E [mm] 183 Weight approx. [kg] 6.8 -
1900022710038
B1H 10C-KPL-H-HIGH10-22MM-LACK
Reference no. 710038 Working load limit [kg] 19000 for nominal chain thickness [mm] 22 Hook opening width G [mm] 64 hook base height H [mm] 62 Hook thickness A [mm] 52 Distance suspension point E [mm] 239 Weight approx. [kg] 8.8
Working load limit [kg]
1400
for nominal chain thickness [mm]
6
Reference no.
502275
-
Details
B1H 10C-CPL-H-HIGH10-6MM-COAT
Reference no. 502275 Working load limit [kg] 1400 for nominal chain thickness [mm] 6 Hook opening width G [mm] 19 hook base height H [mm] 20 Hook thickness A [mm] 15 Distance suspension point E [mm] 73 Weight approx. [kg] 0.29
Working load limit [kg]
2500
for nominal chain thickness [mm]
8
Reference no.
502277
-
Details
B1H 10C-CPL-H-HIGH10-8MM-COAT
Reference no. 502277 Working load limit [kg] 2500 for nominal chain thickness [mm] 8 Hook opening width G [mm] 26 hook base height H [mm] 27 Hook thickness A [mm] 19 Distance suspension point E [mm] 98 Weight approx. [kg] 0.65
Working load limit [kg]
4000
for nominal chain thickness [mm]
10
Reference no.
502278
-
Details
B1H 10C-CPL-H-HIGH10-10MM-COAT
Reference no. 502278 Working load limit [kg] 4000 for nominal chain thickness [mm] 10 Hook opening width G [mm] 30 hook base height H [mm] 33 Hook thickness A [mm] 25 Distance suspension point E [mm] 113 Weight approx. [kg] 1.3
Working load limit [kg]
6700
for nominal chain thickness [mm]
13
Reference no.
502279
-
Details
B1H 10C-CPL-H-HIGH10-13MM-COAT
Reference no. 502279 Working load limit [kg] 6700 for nominal chain thickness [mm] 13 Hook opening width G [mm] 38 hook base height H [mm] 40 Hook thickness A [mm] 32.2 Distance suspension point E [mm] 133 Weight approx. [kg] 2.42
Working load limit [kg]
10000
for nominal chain thickness [mm]
16
Reference no.
502276
-
Details
B1H 10C-CPL-H-HIGH10-16MM-COAT
Reference no. 502276 Working load limit [kg] 10000 for nominal chain thickness [mm] 16 Hook opening width G [mm] 45 hook base height H [mm] 48 Hook thickness A [mm] 38.5 Distance suspension point E [mm] 157 Weight approx. [kg] 3.45
Working load limit [kg]
16000
for nominal chain thickness [mm]
20
Reference no.
710037
-
Details
B1H 10C-KPL-H-HIGH10-20MM-LACK
Reference no. 710037 Working load limit [kg] 16000 for nominal chain thickness [mm] 20 Hook opening width G [mm] 53 hook base height H [mm] 53 Hook thickness A [mm] 51 Distance suspension point E [mm] 183 Weight approx. [kg] 6.8
Working load limit [kg]
19000
for nominal chain thickness [mm]
22
Reference no.
710038
-
Details
B1H 10C-KPL-H-HIGH10-22MM-LACK
Reference no. 710038 Working load limit [kg] 19000 for nominal chain thickness [mm] 22 Hook opening width G [mm] 64 hook base height H [mm] 62 Hook thickness A [mm] 52 Distance suspension point E [mm] 239 Weight approx. [kg] 8.8
