Polytex® lashing strap system RS-25 MINI

Polytex® lashing strap system RS-25 MINI
Multi-purpose system with push-ratchet for lighter loads such as in-plant transport securing or pallet strapping.
Technical data

Ratchet prestressing force

  • 50 daN

Lashing capacity strapping

  • 500 daN

Colour harness strap

  • pink

Width harness strap

  • 25 mm

Material harness strap

  • polyester

Marking

  • Polytex® logo

Standard

  • DIN EN 12195-2

Operating temperature

  • –40 °C to +100 °C

Performance class

  • Multi-purpose system

Type of ratchet

  • Compact standard push-ratchet

Number of teeth on ratchet

  • 10 pcs

Lever length

  • 90 mm

Handle length

  • 105 mm

Version Strap

  • Lashing strap system with ratchet
Options

Options on request

  • with individual imprint
  • further useful lengths
  • further hook types
Product variants
Effective length WLL [m]
Lashing capacity direct pull LC
Lashing capacity strapping LC [daN]
Hook type
Reference no.
Details
  • 4
    500
    without hook
    473811
    Z12 RMI-500-4M
    Reference no. 473811
    Effective length WLL [m] 4
    Lashing capacity strapping LC [daN] 500
    Hook type without hook
    System parts Quantity one-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.31
    produkt_laenge_hebel_met_td 90
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_griff_met_td 105
  • 6
    500
    without hook
    473813
    Z12 RMI-500-6M
    Reference no. 473813
    Effective length WLL [m] 6
    Lashing capacity strapping LC [daN] 500
    Hook type without hook
    System parts Quantity one-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.36
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
    produkt_laenge_griff_met_td 105
  • 4
    250 [daN]
    500
    Wire claw hook
    473815
    Z22 RMI-250-KDH_KDH-4M
    Reference no. 473815
    Effective length WLL [m] 4
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type Wire claw hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 1.51
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
    produkt_laenge_griff_met_td 105
  • 6
    250 [daN]
    500
    Wire claw hook
    473816
    Z22 RMI-250-KDH_KDH-6M
    Reference no. 473816
    Effective length WLL [m] 6
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type Wire claw hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 1.56
    produkt_laenge_griff_met_td 105
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
  • 4
    250 [daN]
    500
    PVC-coated S-hook
    473817
    Z22 RMI-250-SPVC_SPVC-4M
    Reference no. 473817
    Effective length WLL [m] 4
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type PVC-coated S-hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.45
    produkt_laenge_hebel_met_td 90
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_griff_met_td 105
  • 6
    250 [daN]
    500
    PVC-coated S-hook
    473818
    Z22 RMI-250-SPVC_SPVC-6M
    Reference no. 473818
    Effective length WLL [m] 6
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type PVC-coated S-hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.5
    produkt_laenge_griff_met_td 105
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
Effective length WLL [m] 4
Lashing capacity strapping LC [daN] 500
Hook type without hook
Reference no. 473811
  • Details
    Z12 RMI-500-4M
    Reference no. 473811
    Effective length WLL [m] 4
    Lashing capacity strapping LC [daN] 500
    Hook type without hook
    System parts Quantity one-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.31
    produkt_laenge_hebel_met_td 90
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_griff_met_td 105
Effective length WLL [m] 6
Lashing capacity strapping LC [daN] 500
Hook type without hook
Reference no. 473813
  • Details
    Z12 RMI-500-6M
    Reference no. 473813
    Effective length WLL [m] 6
    Lashing capacity strapping LC [daN] 500
    Hook type without hook
    System parts Quantity one-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.36
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
    produkt_laenge_griff_met_td 105
Effective length WLL [m] 4
Lashing capacity direct pull LC 250 [daN]
Lashing capacity strapping LC [daN] 500
Hook type Wire claw hook
Reference no. 473815
  • Details
    Z22 RMI-250-KDH_KDH-4M
    Reference no. 473815
    Effective length WLL [m] 4
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type Wire claw hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 1.51
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
    produkt_laenge_griff_met_td 105
Effective length WLL [m] 6
Lashing capacity direct pull LC 250 [daN]
Lashing capacity strapping LC [daN] 500
Hook type Wire claw hook
Reference no. 473816
  • Details
    Z22 RMI-250-KDH_KDH-6M
    Reference no. 473816
    Effective length WLL [m] 6
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type Wire claw hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 1.56
    produkt_laenge_griff_met_td 105
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
Effective length WLL [m] 4
Lashing capacity direct pull LC 250 [daN]
Lashing capacity strapping LC [daN] 500
Hook type PVC-coated S-hook
Reference no. 473817
  • Details
    Z22 RMI-250-SPVC_SPVC-4M
    Reference no. 473817
    Effective length WLL [m] 4
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type PVC-coated S-hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.45
    produkt_laenge_hebel_met_td 90
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_griff_met_td 105
Effective length WLL [m] 6
Lashing capacity direct pull LC 250 [daN]
Lashing capacity strapping LC [daN] 500
Hook type PVC-coated S-hook
Reference no. 473818
  • Details
    Z22 RMI-250-SPVC_SPVC-6M
    Reference no. 473818
    Effective length WLL [m] 6
    Lashing capacity direct pull LC 250 [daN]
    Lashing capacity strapping LC [daN] 500
    Length fixed end [m] 0.5
    Hook type PVC-coated S-hook
    System parts Quantity two-piece
    Ratchet prestressing force STF [daN] 50
    Weight approx. [kg] 0.5
    produkt_laenge_griff_met_td 105
    produkt_anzahl_zaehne_ratsche_td 10
    produkt_laenge_hebel_met_td 90
