Star-Speedline electric chain hoist with electric running gear

Star-Speedline electric chain hoist with electric running gear
Electric chain hoist with electric running gear (approx. 20 m/min) and standard end position cut-off (at 24 V AC) suitable for all standard applications. The final assembly is done by the customer on site. The power is supplied from the factory.
Technical data

Operating temperature

  • –20 °C to +40 °C

Power supply

  • Without mains cable

Overheating protection

  • Temperature monitor for lifting motor

Control line

  • 3 m chain length = 1.7 m; 6 m chain length = 4,5 m;10 m chain length = 8,5 m

Impact protector

  • Limit position switch-off for limiting the highest and lowest load position

Operating voltage

  • 400 V, 3 ph, 50 Hz

Insulation class

  • F

Overload protection

  • Friction coupling

Chain stores

  • including

Protection class

  • IP 55

Lifting method

  • Main and fine stroke

Controller

  • Contactor control 24V AC
Options

Options on request

  • Radio remote control incl. travel limit switch
  • in further lifting heights
Product variants
Working load limit [kg]
Chain length LK [m]
Reference no.
Details
  • 500
    3
    496011
    KFE STE-500KG-3M
    Reference no. 496011
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 73 [kg]
  • 500
    6
    496012
    KFE STE-500KG-6M
    Reference no. 496012
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 77.5 [kg]
  • 500
    10
    496013
    KFE STE-500KG-10M
    Reference no. 496013
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 83.5 [kg]
  • 1000
    3
    496014
    KFE STE-1000KG-3M
    Reference no. 496014
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 73 [kg]
  • 1000
    6
    496015
    KFE STE-1000KG-6M
    Reference no. 496015
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 77.5 [kg]
  • 1000
    10
    496016
    KFE STE-1000KG-10M
    Reference no. 496016
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 83.5 [kg]
  • 1600
    3
    496017
    KFE STE-1600KG-3M
    Reference no. 496017
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 124.4 [kg]
  • 1600
    6
    496018
    KFE STE-1600KG-6M
    Reference no. 496018
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 131 [kg]
  • 1600
    10
    496019
    KFE STE-1600KG-10M
    Reference no. 496019
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 139.8 [kg]
  • 2000
    3
    496020
    KFE STE-2000KG-3M
    Reference no. 496020
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 82.2 [kg]
  • 2000
    6
    496021
    KFE STE-2000KG-6M
    Reference no. 496021
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 90 [kg]
  • 2000
    10
    496022
    KFE STE-2000KG-10M
    Reference no. 496022
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 100.4 [kg]
  • 2500
    3
    496023
    KFE STE-2500KG-3M
    Reference no. 496023
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 182.4 [kg]
  • 2500
    6
    496024
    KFE STE-2500KG-6M
    Reference no. 496024
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 192 [kg]
  • 2500
    10
    496025
    KFE STE-2500KG-10M
    Reference no. 496025
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 204.8 [kg]
  • 3200
    3
    496026
    KFE STE-3200KG-3M
    Reference no. 496026
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 138 [kg]
  • 3200
    6
    496027
    KFE STE-3200KG-6M
    Reference no. 496027
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 150 [kg]
  • 3200
    10
    496028
    KFE STE-3200KG-10M
    Reference no. 496028
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 166 [kg]
  • 5000
    3
    496029
    KFE STE-5000KG-3M
    Reference no. 496029
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 207 [kg]
  • 5000
    6
    496030
    KFE STE-5000KG-6M
    Reference no. 496030
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 225 [kg]
  • 5000
    10
    496031
    KFE STE-5000KG-10M
    Reference no. 496031
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 249 [kg]
Working load limit [kg] 500
Chain length LK [m] 3
Reference no. 496011
  • Details
    KFE STE-500KG-3M
    Reference no. 496011
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 73 [kg]
Working load limit [kg] 500
Chain length LK [m] 6
Reference no. 496012
  • Details
    KFE STE-500KG-6M
    Reference no. 496012
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 77.5 [kg]
Working load limit [kg] 500
Chain length LK [m] 10
Reference no. 496013
  • Details
    KFE STE-500KG-10M
    Reference no. 496013
    Working load limit [kg] 500
    Type 500/1-8/2
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 2
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 83.5 [kg]
Working load limit [kg] 1000
Chain length LK [m] 3
Reference no. 496014
  • Details
    KFE STE-1000KG-3M
    Reference no. 496014
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 73 [kg]
Working load limit [kg] 1000
Chain length LK [m] 6
Reference no. 496015
  • Details
    KFE STE-1000KG-6M
    Reference no. 496015
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 77.5 [kg]
Working load limit [kg] 1000
Chain length LK [m] 10
Reference no. 496016
  • Details
    KFE STE-1000KG-10M
    Reference no. 496016
    Working load limit [kg] 1000
    Type 1000/1-6/1.5
    Number of legs AS 1
    Lifting height max Hmax 24
    Main stroke speed [m/min] 6
    Fine stroke speed [m/min] 1.5
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 83.5 [kg]
Working load limit [kg] 1600
Chain length LK [m] 3
Reference no. 496017
  • Details
    KFE STE-1600KG-3M
    Reference no. 496017
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 124.4 [kg]
Working load limit [kg] 1600
Chain length LK [m] 6
Reference no. 496018
  • Details
    KFE STE-1600KG-6M
    Reference no. 496018
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 131 [kg]
Working load limit [kg] 1600
Chain length LK [m] 10
Reference no. 496019
  • Details
    KFE STE-1600KG-10M
    Reference no. 496019
    Working load limit [kg] 1600
    Type 1600/1-8/1
    Number of legs AS 1
    Lifting height max Hmax 30
    Main stroke speed [m/min] 8
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 139.8 [kg]
Working load limit [kg] 2000
Chain length LK [m] 3
Reference no. 496020
  • Details
    KFE STE-2000KG-3M
    Reference no. 496020
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 3
    Weight approx. [kg] 82.2 [kg]
Working load limit [kg] 2000
Chain length LK [m] 6
Reference no. 496021
  • Details
    KFE STE-2000KG-6M
    Reference no. 496021
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 6
    Weight approx. [kg] 90 [kg]
Working load limit [kg] 2000
Chain length LK [m] 10
Reference no. 496022
  • Details
    KFE STE-2000KG-10M
    Reference no. 496022
    Working load limit [kg] 2000
    Type 2000/2-3/0.75
    Number of legs AS 2
    Lifting height max Hmax 12
    Main stroke speed [m/min] 3
    Fine stroke speed [m/min] 0.75
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 21
    Chain link width 7.2
    for beam flange width min [mm] 66
    for beam flange width max [mm] 135
    Chain length LK [m] 10
    Weight approx. [kg] 100.4 [kg]
Working load limit [kg] 2500
Chain length LK [m] 3
Reference no. 496023
  • Details
    KFE STE-2500KG-3M
    Reference no. 496023
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 182.4 [kg]
Working load limit [kg] 2500
Chain length LK [m] 6
Reference no. 496024
  • Details
    KFE STE-2500KG-6M
    Reference no. 496024
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 192 [kg]
Working load limit [kg] 2500
Chain length LK [m] 10
Reference no. 496025
  • Details
    KFE STE-2500KG-10M
    Reference no. 496025
    Working load limit [kg] 2500
    Type 2500/1-10/2.5
    Number of legs AS 1
    Lifting height max Hmax 20
    Main stroke speed [m/min] 10
    Fine stroke speed [m/min] 2.5
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 204.8 [kg]
Working load limit [kg] 3200
Chain length LK [m] 3
Reference no. 496026
  • Details
    KFE STE-3200KG-3M
    Reference no. 496026
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 138 [kg]
Working load limit [kg] 3200
Chain length LK [m] 6
Reference no. 496027
  • Details
    KFE STE-3200KG-6M
    Reference no. 496027
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 150 [kg]
Working load limit [kg] 3200
Chain length LK [m] 10
Reference no. 496028
  • Details
    KFE STE-3200KG-10M
    Reference no. 496028
    Working load limit [kg] 3200
    Type 3200/2-4/1
    Number of legs AS 2
    Lifting height max Hmax 15
    Main stroke speed [m/min] 4
    Fine stroke speed [m/min] 1
    Duty cycle, main stroke [%] 60
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 240
    Chain link length 27
    Chain link width 9
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 166 [kg]
Working load limit [kg] 5000
Chain length LK [m] 3
Reference no. 496029
  • Details
    KFE STE-5000KG-3M
    Reference no. 496029
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 3
    Weight approx. [kg] 207 [kg]
Working load limit [kg] 5000
Chain length LK [m] 6
Reference no. 496030
  • Details
    KFE STE-5000KG-6M
    Reference no. 496030
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 6
    Weight approx. [kg] 225 [kg]
Working load limit [kg] 5000
Chain length LK [m] 10
Reference no. 496031
  • Details
    KFE STE-5000KG-10M
    Reference no. 496031
    Working load limit [kg] 5000
    Type 5000/2-5/1.25
    Number of legs AS 2
    Lifting height max Hmax 10
    Main stroke speed [m/min] 5
    Fine stroke speed [m/min] 1.25
    Duty cycle, main stroke [%] 40
    Duty cycle, fine stroke [%] 25
    Travel speed inching [m/min] 5
    Travel speed fast gear [m/min] 20
    Number of switching operations per hour max [St/h] 150
    Chain link length 31
    Chain link width 11.3
    for beam flange width min [mm] 82
    for beam flange width max [mm] 155
    Chain length LK [m] 10
    Weight approx. [kg] 249 [kg]
Contact
Market Contact Location type
All other markets
 PFEIFER Seil- und Hebetechnik GmbH
Dr.-Karl-Lenz-Straße 66
DE-87700 Memmingen
Tel. +49 8331 937-9623
Fax +49 8331 937-380
E-Mail verkauf-azs@pfeifer.de
Web www.pfeifer.info
 Parent company/Head office
Germany
 PFEIFER Seil- und Hebetechnik GmbH
Dr.-Karl-Lenz-Straße 66
DE-87700 Memmingen
Mobile Services
Tel. +49 800 7237244
Fax +49 8331 937-198
E-Mail pruefservice-azs@pfeifer.de
Web www.pfeifer.info
 Service centre
Germany
 PFEIFER Seil- und Hebetechnik GmbH
Dr.-Karl-Lenz-Strasse 66
DE-87700 Memmingen
Academy
Tel. +49 8331 937-462
E-Mail academy@pfeifer.de
Web www.pfeifer.info
 Service centre
Austria
 PFEIFER Seil- und Hebetechnik GmbH
Harterfeldweg 2
AT-4481 Asten
Tel. +43 7224 662 24-0
Fax +43 7224 662 24-13
E-Mail info@pfeifer-austria.at
Web www.pfeifer-austria.at
 Sales subsidiary
France
 PFEIFER SOGEQUIP S.à.r.l.
Zone Ind. Schifflange-Foetz
LU-3844 Schifflange
Tel. +33 676 54 42 68 / +352 57 42-42
Fax +352 57 42-62
E-Mail info@pfeifer-sogequip.lu
Web www.pfeifer-sogequip.lu
 Sales subsidiary
Luxemburg
 PFEIFER SOGEQUIP S.à.r.l.
Zone Ind. Schifflange-Foetz
LU-3844 Schifflange
Tel. +352 57 42-42
Fax +352 57 42-62
E-Mail info@pfeifer-sogequip.lu
Web www.pfeifer-sogequip.lu
 Sales subsidiary
Poland
 PFEIFER Technika Linowa i Dźwigowa Sp. z o.o.
ul. Wrocławska 68
55-330 Krępice k/Wrocławia
Tel. +48 71 30 23 700
E-Mail info@pfeifer.pl
Web www.pfeifer.pl
 Sales subsidiary

Feel free to contact us

Tel.

+49 8331 937-9623

Inquiry

please leave empty!
* Required fields

Cookie settings

We use cookies to optimise our web page for you. By continuing to use the web page you agree to the use of cookies. Further information about cookies can be found in our data protection declaration.

Required cookies

Required cookies are mandatory for the basic functions of the website. Without these cookies, you will unfortunately not be able to use our website. These cookies are always set when you use the website. No personal data is collected or stored.

Functional cookies

These cookies allow us to analyze website usage so that we can measure and improve its performance. No personal data is collected or stored.

Data protection declaration
