SH-Permanent magnet transporter

SH-Permanent magnet transporter
For the manual or crane transport of small materials and workpieces. The magnetic transporter is detached from the load with the smooth-running, mechanical release mechanism.
Technical data

Safety factor

  • SH 12: 2, SH 35 K: 3

Operating temperature

  • –10 °C to +80 °C

Suspension

  • Rigid attachment eye

Range of application Magnets

  • Transport

load types Magnets

  • Standard
Safety instruction
  • Persons with heart pacemakers are prohibited from using the device!
Product variants
Type
Tractive force max [kg]
Lifting capacity max [kg]
Reference no.
Details
  • SH 12
    60
    120
    307152
    MPL-MSH-EN-ASFFALG-SH12-120-2MM
    Reference no. 307152
    Type SH 12
    Sheet thickness flat material min [mm] 2
    Tractive force max [kg] 60
    Lifting capacity max [kg] 120
    Holding surface Length [mm] 133
    Holding surface Width [mm] 106
    Weight approx. [kg] 1.3 [kg]
  • SH 35 K
    84
    250
    114593
    MPL-MSH-EN-ASSFALG-SH35-K-250-3MM
    Reference no. 114593
    Type SH 35 K
    Sheet thickness flat material min [mm] 3
    Tractive force max [kg] 84
    Lifting capacity max [kg] 250
    Holding surface Length [mm] 190
    Holding surface Width [mm] 110
    Weight approx. [kg] 4.6 [kg]
Type SH 12
Tractive force max [kg] 60
Lifting capacity max [kg] 120
Reference no. 307152
  • Details
    MPL-MSH-EN-ASFFALG-SH12-120-2MM
    Reference no. 307152
    Type SH 12
    Sheet thickness flat material min [mm] 2
    Tractive force max [kg] 60
    Lifting capacity max [kg] 120
    Holding surface Length [mm] 133
    Holding surface Width [mm] 106
    Weight approx. [kg] 1.3 [kg]
Type SH 35 K
Tractive force max [kg] 84
Lifting capacity max [kg] 250
Reference no. 114593
  • Details
    MPL-MSH-EN-ASSFALG-SH35-K-250-3MM
    Reference no. 114593
    Type SH 35 K
    Sheet thickness flat material min [mm] 3
    Tractive force max [kg] 84
    Lifting capacity max [kg] 250
    Holding surface Length [mm] 190
    Holding surface Width [mm] 110
    Weight approx. [kg] 4.6 [kg]
